Ortofon 2M Bronze Cartridge

2M Bronze - Bona fide precision

Listening to your records with the 2M Bronze is like hearing them for the first time, and you get to fall in love with the songs all over again. That is what hi-fi means to us, and that is what you get with the 2M Bronze.

Nude fine line diamond stylus

The 2M Bronze features a Nude Fine Line diamond particularly suited for demanding applications. The slim profile of the Fine Line stylus will track even the highest frequency information.

Compatibility

Created to facilitate simple installation of the cartridge and to ensure compatibility with the dimensions and weights of today's most popular turntables, the 2M Series offers four distinct product versions:



The 2M is for most common turntables on the market, the 2M Premounted for customers who wish direct and easy mounting and replacement on their S-shaped tonearm, the 2M Verso for bottom mount headshells, and the 2MR, which is designed with cartridge housing tailored for turntables and tonearms like Rega, matching their requirement for low-form factor cartridges.

Channel balance at 1 kHz: 1 dB
Output voltage at 1 kHz, 5cm/sec: 5 mV
Channel separation at 1 kHz: 26 dB
Channel separation at 15 kHz: 15 dB
Frequency response 20 Hz - 20 kHz: 2 / - 0 dB
Tracking ability at 315Hz at recommended tracking force: 80 µm
Compliance, dynamic, lateral: 22 µm/mN
Stylus type: Nude Fine Line
Stylus tip radius: r/R 8/40 µm
Tracking force range: 1.4-1.7 g (14-17 mN)
Tracking force, recommended: 1.5 g (15 mN)
Tracking angle: 20°
Internal impedance, DC resistance: 1.2 kOhm
Cartridge colour: Black/Bronze
Cartridge weight: 7.2 g
Premounted cartridge weight: 16.7 g
Recommended load resistance: 47 kOhm
Internal inductance: 630 mH
Recommended load capacitance: 150-300 pF

2M Series styli interchangeability:

The 2M Series' engines, coils and magnets configurations are not identical: Red and Blue are identical, so are the Bronze and Black and so are the true mono variants 2M Mono and 2M 78. Likewise, 2M series styli are interchangeable within the below combinations:

- 2M Red, 2M Blue and 2M Silver

- 2M Bronze, 2M Black and 2m Black LVB 250

 2M Mono and 2M 78
